This controller is part of the Modicon MC80 range, an offer of compact processors. It features 8 discrete inputs and 8 discrete outputs, It does not support analog inputs. It provides Modbus, CANopen, and Ethernet connection. It has a 24 V power consumption. EcoStruxure Control Expert programming software is required to set up the Modicon MC80 controller. It weighs 0.980kg. It is fit for thermo solar and tower power applications. Modicon MC80 PLCs comply to IEC, UL, and CSA standards. It is compatible with terminal blocks for high-speed counter and discrete I/O modules. MC80 PLC can be mounted on DIN rails of 35mm wide or on panels. MC80 controllers are completely integrated with the other Modicon controllers, programmed and commissioned with EcoStruxure Control Expert. Modicon MC80 range features automated platform processors which are compact with discrete I/O functions, analog input functions, counting functions, and communication functions.

Brand

Schneider Electric

Range

Modicon MC80

Part No

BMKC8020310

Weight (kg)

1.20 kg

Type

Modicon MC80

Supporting protocol for IEC 60870

FALSE

Supporting protocol for DNP3

FALSE

Supporting protocol for SERCOS

FALSE

Number of HW-interfaces other

1

Number of HW-interfaces USB

1

SIL according to IEC 61508

None

With optical interface

FALSE

Max. number of time switches

2

System accessory

FALSE

Additional program memory possible

FALSE

Performance level according to EN ISO 13849-1

None

Certified for UL hazardous location division 2

FALSE

Radio standard GPRS

FALSE

Height

100

Supporting protocol for INTERBUS-Safety

FALSE

Certified for UL hazardous location class I

FALSE

Certified for UL hazardous location class III

FALSE

Certified for UL hazardous location division 1

FALSE

Certified for UL hazardous location class II

FALSE

Width

220

Supporting protocol for EtherCAT

FALSE

Redundancy

FALSE

Supporting protocol for AS-Interface Safety at Work

FALSE

Radio standard GSM

FALSE

Explosion safety category for dust

None

Radio standard UMTS

FALSE

Depth

105

Explosion safety category for gas

None

Supporting protocol for DeviceNet Safety

FALSE

Supporting protocol for EtherNet/IP

FALSE

Supporting protocol for Foundation Fieldbus

FALSE

Certified for UL hazardous location group C (ethylene)

FALSE

Certified for UL hazardous location group A (acetylene)

FALSE

Certified for UL hazardous location group B (hydrogen)

FALSE

Certified for UL hazardous location group F (carbonaceous dusts)

FALSE

Certified for UL hazardous location group G (non-conductive dusts)

FALSE

Certified for UL hazardous location group D (propane)

FALSE

Certified for UL hazardous location group E (metal dusts)

FALSE

With display

FALSE

Supporting protocol for SafetyBUS p

FALSE

Processing time (1K, binary operation)

0.06

Model

Compact

Voltage type (supply voltage)

AC/DC

Type of memory

NVRAM

Long-Term Evolution (LTE)

FALSE

Supporting protocol for PROFINET CBA

FALSE

Supporting protocol for PROFINET IO

FALSE

Supporting protocol for PROFIsafe

FALSE

Memory size

3840

Supporting protocol for ASI

FALSE

Radio standard Bluetooth

FALSE

Radio standard WLAN 802.11

FALSE

Supporting protocol for PROFIBUS

FALSE

Appendant operation agent (Ex ia)

FALSE

Front built-in possible

FALSE

Supporting protocol for TCP/IP

TRUE

Supporting protocol for KNX

FALSE

Supporting protocol for CAN

TRUE

Appendant operation agent (Ex ib)

FALSE

IO link master

FALSE

Supporting protocol for INTERBUS

FALSE

Supporting protocol for IEC 61850 Ethernet

FALSE

Rail mounting possible

TRUE

Supporting protocol for DeviceNet

FALSE

Number of digital outputs

12

Suitable for safety functions

FALSE

Supporting protocol for Modbus

TRUE

Supporting protocol for Data-Highway

FALSE

Number of digital inputs

20

Supply voltage DC

24 Volt

Rack-assembly possible

FALSE

Supporting protocol for LON

FALSE

Supporting protocol for other bus systems

FALSE

Supporting protocol for SUCONET

FALSE

Wall mounting/direct mounting

TRUE

Number of HW-interfaces RS-485

1

Number of HW-interfaces industrial Ethernet

2

Number of HW-interfaces RS-232

1
