digital output module - 4O - 30V DC/230V AC - 5A - relay - 4 C/O - Schneider Electric - TM5SDO4R
digital output module - 4O - 30V DC/230V AC - 5A - relay - 4 C/O - Schneider Electric - TM5SDO4R

TM5SDO4R

digital output module - 4O - 30V DC/230V AC - 5A - relay - 4 C/O - Schneider Electric - TM5SDO4R

Automation

List Price £156.54 +VAT

Our Price £125.23 +VAT

SAVE 21% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This discrete output module provides 4 discrete outputs with relay discrete output. Its output voltage limits are 184 to 276V AC, 24 to 36V DC, and provides a maximum power dissipation of 2.3W. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an isolation between channel and bus at 500V AC. It is equipped with NO/NC contact. It is an IP20 rated product. Its housing colour is black.It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 and PacDrive LMC motion controllers and Modicon M258 logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Brand
Schneider Electric
Range
Modicon TM5 IP20 modular I/O system
Part No
TM5SDO4R
Weight (kg)
0.05 kg
Type
Modicon TM5 IP20 modular I/O system
Type of electric connection
Plug-in connection
Output, current
5
Voltage type of supply voltage
AC/DC
Short-circuit protection, outputs available
FALSE
SIL according to IEC 61508
None
Digital inputs configurable
FALSE
Type of digital output
Relay
Digital outputs configurable
FALSE
Appendant operation agent (Ex ia)
FALSE
Performance level acc. EN ISO 13849-1
None
Permitted voltage at output
24…36 V
Supply voltage AC 50 Hz
230 V
Supply voltage AC 60 Hz
230 V
Height
99
Time delay at signal exchange
10 ms
Appendant operation agent (Ex ib)
FALSE
Type of output voltage
AC/DC
Category according to EN 954-1
1
Width
12.5
Suitable for safety functions
FALSE
Number of digital outputs
4
Redundancy
FALSE
Supply voltage DC
30 V
Explosion safety category for dust
None
Depth
75
Explosion safety category for gas
None

Datasheet for TM5SDO4R - digital output module - 4O - 30V DC/230V AC - 5A - relay - 4 C/O - Schneider Electric - TM5SDO4R
