TeSys K control relay - 2 NO + 2 NC - <= 690 V - 12 V DC standard coil - Schneider Electric - CA3KN22JD
TeSys K control relay - 2 NO + 2 NC - <= 690 V - 12 V DC standard coil - Schneider Electric - CA3KN22JD

CA3KN22JD

TeSys K control relay - 2 NO + 2 NC - <= 690 V - 12 V DC standard coil - Schneider Electric - CA3KN22JD

Control

List Price £40.50 +VAT

Our Price £30.38 +VAT

SAVE 25% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 12V DC control circuit with no inrush consumption, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), (RoHS/REACh).
Brand
Schneider Electric
Range
TeSys K, D, SK Control Relays
Part No
CA3KN22JD
Weight (kg)
0.22 kg
Type
TeSys K, D, SK Control Relays
Interface
FALSE
Connection type auxiliary circuit
Screw connection
Number of auxiliary contacts as normally closed contact
2
Number of auxiliary contacts as normally open contact
2
With LED indication
FALSE
Mounting method
DIN-rail/screw
Rated operation current Ie, 400 V
10
Rated control supply voltage Us at DC
12 V
Voltage type for actuating
DC
Manual operation possible
FALSE

Datasheet for CA3KN22JD - TeSys K control relay - 2 NO + 2 NC - <= 690 V - 12 V DC standard coil - Schneider Electric - CA3KN22JD
