LP1K09105BD
LP1K09105BD
TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 24 V DC coil - Schneider Electric - LP1K09105BD
Control
List Price £41.02
+VAT
Our Price £30.77
+VAT
SAVE 25% OFF List Price
Add to basket
Estimated delivery between 7-10 working days
Get in touch
Product description
Specifications
Downloads
TeSys K contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V DC coil, 1NO built-in auxiliary contact, connection by solder pins for printed circuit boards. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC),
Brand
Schneider Electric
Range
TeSys K contactors
Part No
LP1K09105BD
Weight (kg)
0.25 kg
Type
TeSys K contactors
Type of electrical connection of main circuit
PCB connection
Rated operation power at AC-3, 400 V
4
Number of main contacts as normally open contact
3
craft\elements\db\ElementQuery
1
craft\elements\db\ElementQuery
FALSE
craft\elements\db\ElementQuery
20
craft\elements\db\ElementQuery
6
Rated control supply voltage Us at DC
24 V
Rated operation current Ie at AC-3, 400 V
9
craft\elements\db\ElementQuery
DC
craft\elements\db\ElementQuery
2.2
Datasheet for LP1K09105BD - TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 24 V DC coil - Schneider Electric - LP1K09105BD
Download
