redundancy module - 40A - for regulated SMPS - Schneider Electric - ABL8RED24400
redundancy module - 40A - for regulated SMPS - Schneider Electric - ABL8RED24400

ABL8RED24400

redundancy module - 40A - for regulated SMPS - Schneider Electric - ABL8RED24400

Control

£152.02 +VAT
Estimated delivery between 7-10 working days
Get in touch
This ABL8 redundancy solution supplies direct current voltage. It has a rated input of 24V to 28.8V DC, a rated output current of 40A. This redundancy solution is designed to bring continuity to auxiliary power even during failure of one out of 2 power supply units. It can be used to supply the nominal power to the application even if one of the power supplies is inoperable or otherwise unavailable. It has LED diagnostics indicator available in the front for troubleshooting instantly. It weighs 0,700kg. It is a functionnal module for power supply for industrial use, rail mounting. It conforms to UL 508, CSA C22.2 No 60950-1 standards. It is certified by EAC, RCM. This functional module is mainly compatible with Modicon ABL8RP and Modicon ABL8WP Universal power supplies. It has LED diagnostics indicator available in the front for troubleshooting instantly. It installs on DIN rail. It brings energy to your automated systems. Designed for simple machines and applications, modular power supplies are primarily appreciated for their extreme compactness.
Brand
Schneider Electric
Range
Power supplies for industrial use, rail mounting
Part No
ABL8RED24400
Weight (kg)
0.59 kg
Type
Power supplies for industrial use, rail mounting
Direct mounting possible
FALSE
Type of electric connection
Screw connection
Voltage type of supply voltage
DC
Stabilized
TRUE
Modular version
TRUE
SIL according to IEC 61508
None
Short-circuit-proof
TRUE
Performance level acc. EN ISO 13849-1
None
Power output
145
Height
146
Nominal value output current 1
40
Degree of protection (IP)
IP10
Rated supply voltage at DC
24 V
Nominal value output voltage 1
24
Max. output current 1
40
Output voltage stabilized
TRUE
Width
44
Rail mounting possible
TRUE
Wall mounting possible
FALSE
Suitable for safety functions
TRUE
Depth
140
1st secondary output voltage
24 V
Secondary voltage adjustable
TRUE

Datasheet for ABL8RED24400 - redundancy module - 40A - for regulated SMPS - Schneider Electric - ABL8RED24400
