Brand
-
Schneider Electric
-
Range
-
Advantys Telefast ABE 7
-
Part No
-
ABE7H16S21
-
Weight (kg)
-
0.36 kg
-
Type
-
Advantys Telefast ABE 7
-
Number of sensor-/actuator-slots
-
1
-
Connection for NPN-sensors
-
FALSE
-
Max. current carrying capacity per socket
-
1.8
-
Operating voltage
-
24 V
-
Max. total current
-
1.8
-
Max. current carrying capacity per I/O signal
-
0.5
-
Number of poles sensor/actuator slots
-
16
-
Colour housing
-
Grey
-
Thread sleeves sensor/actuator slots
-
Other
-
Material of contact surface
-
Other
-
With potential separation
-
FALSE
-
Material contact body
-
Other copper alloys
-
Height
-
70
-
Degree of protection (IP)
-
IP2X
-
Width
-
125
-
Rated voltage
-
24
-
Pollution degree
-
2
-
With LED indication
-
TRUE
-
Number of channels per connector slot
-
16
-
Material housing
-
Plastic
-
Explosion safety category for dust
-
None
-
Explosion safety category for gas
-
None
-
Cable length configurable
-
TRUE
-
Material insulation body
-
Other
-
Cable outer diameter for cable gland
-
0 mm
-
Type of branches for sensor-/actuator cables
-
Other
-
Fix cable version suitable for cable guide chain
-
FALSE
-
Operation temperature
-
-5…60 °C
