Brand
-
Schneider Electric
-
Range
-
Modicon X80 I/Os
-
Part No
-
BMXSRA0405
-
Weight (kg)
-
0.39 kg
-
Type
-
Modicon X80 I/Os
-
Input current at signal 1
-
0.65
-
Output, current
-
3
-
Type of electric connection
-
Plug-in connection
-
Voltage type of supply voltage
-
DC
-
Short-circuit protection, outputs available
-
TRUE
-
SIL according to IEC 61508
-
None
-
Digital inputs configurable
-
FALSE
-
Type of digital output
-
Relay
-
Digital outputs configurable
-
FALSE
-
Performance level acc. EN ISO 13849-1
-
None
-
Appendant operation agent (Ex ia)
-
FALSE
-
Permitted voltage at output
-
19…30 V
-
Permitted voltage at input
-
19…30 V
-
Type of voltage (input voltage)
-
DC
-
Time delay at signal exchange
-
10…12 ms
-
Height
-
100
-
Appendant operation agent (Ex ib)
-
FALSE
-
Type of output voltage
-
DC
-
Category according to EN 954-1
-
1
-
Width
-
33
-
Number of digital outputs
-
4
-
Suitable for safety functions
-
TRUE
-
Redundancy
-
FALSE
-
Explosion safety category for dust
-
ATEX dust-ex-protection, Cat. 1D
-
Supply voltage DC
-
24 V
-
Depth
-
150
-
Explosion safety category for gas
-
ATEX gas-ex-protection, Cat. 1G
