Composition kit of I/O(TM5SDO12T) + term. block(TM5ACTB12) + bus base(TM5ACBM11) - Schneider Electric - TM5SDO12TK
Composition kit of I/O(TM5SDO12T) + term. block(TM5ACTB12) + bus base(TM5ACBM11) - Schneider Electric - TM5SDO12TK

TM5SDO12TK

Composition kit of I/O(TM5SDO12T) + term. block(TM5ACTB12) + bus base(TM5ACBM11) - Schneider Electric - TM5SDO12TK

Automation

List Price £187.97 +VAT

Our Price £150.38 +VAT

SAVE 20% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This composition kit provides 12 outputs with source output logic and transistor output. It is a composition kit with an output voltage of 24V DC and a maximum power dissipation of 2.04W. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an insulation between channel and bus at 500Vrms AC and no insulation between channels. It is furnished with single wire for electrical connection. It is an IP20 rated product. It is furnished with single wire for electrical connection. It is an IP20 rated product. The housing colour is white. It weighs 0.065kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. The kit includes bus sub-base TM5ACBM11, terminal block TM5ACTB12 and I/O module TM5SDO12T. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Brand
Schneider Electric
Range
Modicon TM5 IP20 modular I/O system
Part No
TM5SDO12TK
Weight (kg)
0.12 kg
Type
Modicon TM5 IP20 modular I/O system
Type of electric connection
Other
Voltage type of supply voltage
DC
Short-circuit protection, outputs available
FALSE
SIL according to IEC 61508
1
Digital inputs configurable
FALSE
Type of digital output
Other
Digital outputs configurable
FALSE
Appendant operation agent (Ex ia)
FALSE
Performance level acc. EN ISO 13849-1
None
Time delay at signal exchange
0.1 ms
Height
99
Appendant operation agent (Ex ib)
FALSE
Category according to EN 954-1
1
Width
12.5
Suitable for safety functions
FALSE
Number of digital outputs
12
Redundancy
FALSE
Number of digital inputs
12
Supply voltage DC
24 V
Explosion safety category for dust
Other
Depth
75
Explosion safety category for gas
Other

Datasheet for TM5SDO12TK - Composition kit of I/O(TM5SDO12T) + term. block(TM5ACTB12) + bus base(TM5ACBM11) - Schneider Electric - TM5SDO12TK
