Triple-headed push button, metal, Ø22, marked, 1 green flush I + 1 red projecting STOP + 1 green flush II, 2 NO + 1 NC - Schneider Electric - XB4BA731327

XB4BA731327

Triple-headed push button, metal, Ø22, marked, 1 green flush I + 1 red projecting STOP + 1 green flush II, 2 NO + 1 NC - Schneider Electric - XB4BA731327

Control

~~List Price £45.06 +VAT~~

Our Price £33.80 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

This Harmony XB4 triple-headed modular push button has 1 red and 2 green buttons, operates with a spring return / impulse mechanism. It has a metal bezel. It is marked with "I", "STOP" and "II" symbols. This 3-headed push button provides a complete 3 button interface to your machines with a single panel cut-out. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments.

Brand: Schneider Electric
Range: Harmony XB4
Part No: XB4BA731327
Weight (kg): 0.13 kg
Type: Harmony XB4
Spring-return: TRUE
Colour front ring: Chrome
Type of electric connection: Screw connection
Hole diameter: 22.5
Material front ring: Metal
Switching function latching: FALSE
Type of button: High
Number of contacts as normally open contact: 2
Construction type lens: Rectangular
Colour button: Red/green
With front ring: TRUE
Suitable for illumination: FALSE
Degree of protection (IP): Other
Number of command positions: 3
Number of contacts as normally closed contact: 1
Degree of protection (NEMA): 4X

Datasheet for XB4BA731327 - Triple-headed push button, metal, Ø22, marked, 1 green flush I + 1 red projecting STOP + 1 green flush II, 2 NO + 1 NC - Schneider Electric - XB4BA731327
