Brand
-
Schneider Electric
-
Range
-
PanelSeT PLM GRP Enclosures
-
Part No
-
IMT36150
-
Weight (kg)
-
0.02 kg
-
Type
-
Thalassa PLM GRP Enclosures
-
Surface protection
-
Untreated
-
Bend radius protection/trumpet flare
-
TRUE
-
With strain relief
-
TRUE
-
For Ex-zone gas
-
None
-
Model
-
Straight
-
For armoured cable
-
FALSE
-
With locknut
-
TRUE
-
Wrench width
-
20
-
Hexagon angular dimension
-
10
-
Multi seal area
-
TRUE
-
Suitable for cable diameter
-
6…12 Millimetre
-
Operating temperature
-
0…960 Degrees celsius
-
RAL-number
-
3000
-
Shock resistant
-
TRUE
-
Degree of protection (IP)
-
IP68
-
Colour
-
Red
-
Type of sealing
-
Membrane
-
Thread type
-
Metric
-
Nominal thread size metric/PG
-
20
-
Glass-fibre reinforced
-
TRUE
-
Separable screw gland
-
TRUE
-
Flat cable coupling
-
FALSE
-
Material
-
Plastic
-
Screened
-
FALSE
-
Nominal thread size inch/gas pipe thread
-
3/4 inch
-
Halogen free
-
TRUE
-
Pitch thread
-
2.5
-
For Ex-Zone dust
-
None
-
Material quality
-
Polyamide (PA)
-
Thread length
-
9
-
EMC-version
-
FALSE
-
Pressure-compensating
-
FALSE
-
Explosion-tested version
-
FALSE
-
Snapping in opening
-
FALSE
