LC2K0910E7

TeSys K reversing contactor - 3P - AC-3 <= 440 V 9 A - 1 NO - 48 V AC coil - Schneider Electric - LC2K0910E7

Control

~~List Price £94.44 +VAT~~

Our Price £70.83 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

Get in touch

TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V). It provides 48V 50/60Hz AC coils, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC)

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LC2K0910E7
Weight (kg): 0.36 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Screw connection
Rated operation power at AC-3, 400 V: 4
Type of electrical connection for auxiliary- and control current circuit: Screw connection
Voltage type (operating voltage): AC
Rated operation power NEMA: 3.73
Height: 58
Rated operation current Ie at AC-3, 400 V: 9
Voltage type for actuating: AC
Degree of protection (IP): IP20
Width: 90
Rated control supply voltage AC 50 Hz: 48 Volt
Rated control supply voltage AC 60 Hz: 48 Volt
Rail mounting possible: FALSE
Number of normally open contacts as main contact: 3
Number of auxiliary contacts as normally open contact: 1
Operating voltage AC 50 Hz: 440 Volt
Depth: 57
Operating voltage AC 60 Hz: 440 Volt
Function: Reversing contactor
Degree of protection (NEMA): Other
