LP5K0910BW3

TeSys K reversing contactor - 3P - AC-3 <= 440 V 9 A - 1 NO - 24 V DC coil - Schneider Electric - LP5K0910BW3

Control

~~List Price £121.78 +VAT~~

Our Price £91.34 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

Get in touch

TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V). It provides low consumption 24V DC coils with transient suppressor module, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC)

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LP5K0910BW3
Weight (kg): 0.45 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Screw connection
Rated operation power at AC-3, 400 V: 4
Type of electrical connection for auxiliary- and control current circuit: Screw connection
Voltage type (operating voltage): DC
Rated operation power NEMA: 3.73
Rated operation current Ie at AC-3, 400 V: 9
Height: 58
Voltage type for actuating: DC
Degree of protection (IP): IP20
Width: 90
Rail mounting possible: FALSE
Number of normally open contacts as main contact: 3
Depth: 57
Operating voltage DC: 440 Volt
Rated control supply voltage DC: 24 Volt
Function: Reversing contactor
Degree of protection (NEMA): Other
