LC2K1210D7
TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 42 V AC coil - Schneider Electric - LC2K1210D7
Automation
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides 42V 50/60Hz AC coils, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Our Price £72.93 +VAT
SAVE 25% OFF List Price
Specifications
- Brand
- Schneider Electric
- Type
- TeSys K contactors
- Range
- TeSys K contactors
- Part No
- LC2K1210D7
- Weight (kg)
- 0.39 kg
Datasheet for LC2K1210D7 - TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 42 V AC coil - Schneider Electric - LC2K1210D7
