TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 24 V AC coil - Schneider Electric - LC2K1210B7
TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 24 V AC coil - Schneider Electric - LC2K1210B7

LC2K1210B7

TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 24 V AC coil - Schneider Electric - LC2K1210B7

Control

List Price £91.69 +VAT

Our Price £68.77 +VAT

SAVE 25% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides 24V 50/60Hz AC coils, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC)
Brand
Schneider Electric
Range
TeSys K contactors
Part No
LC2K1210B7
Weight (kg)
0.37 kg
Type
TeSys K contactors
Type of electrical connection of main circuit
Screw connection
Rated control supply voltage Us at AC 50HZ
24 V
craft\elements\db\ElementQuery
24 V
craft\elements\db\ElementQuery
5.59
craft\elements\db\ElementQuery
AC
Rated operation current Ie at AC-3, 400 V
12
Degree of protection (IP)
IP20
craft\elements\db\ElementQuery
Reversing safety
Rated operation power at AC-3, 400 V
5.5
craft\elements\db\ElementQuery
Other

Datasheet for LC2K1210B7 - TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NO - 24 V AC coil - Schneider Electric - LC2K1210B7

Download
