LP5K12015BW3

TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NC - 24 V DC coil - Schneider Electric - LP5K12015BW3

Automation

TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides low consumption 24V DC coils with transient suppressor module, 2NC built-in auxiliary contacts, connection by solder pins for printed circuit boards. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

~~List Price £139.94 +VAT~~

Our Price £104.96 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days
