LP2K1201BD

TeSys K reversing contactor - 3P - AC-3 <= 440 V 12 A - 1 NC - 24 V DC coil - Schneider Electric - LP2K1201BD

Control

~~List Price £109.36 +VAT~~

Our Price £82.02 +VAT

SAVE 26% OFF List Price

Estimated delivery between 7-10 working days

Get in touch

TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides 24V DC coils, 2NC built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC)

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LP2K1201BD
Weight (kg): 0.45 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Screw connection
Rated operation power at AC-3, 400 V: 5.5
Type of electrical connection for auxiliary- and control current circuit: Screw connection
Voltage type (operating voltage): DC
Rated operation power NEMA: 5.59
Voltage type for actuating: DC
Height: 58
Rated operation current Ie at AC-3, 400 V: 12
Degree of protection (IP): IP20
Width: 90
Rail mounting possible: FALSE
Number of normally open contacts as main contact: 3
Number of auxiliary contacts as normally closed contact: 1
Depth: 57
Operating voltage DC: 440 Volt
Rated control supply voltage DC: 24 Volt
Function: Reversing contactor
Degree of protection (NEMA): Other
