TeSys K contactor - 4P (4 NO) - AC-1 <= 440 V 20 A - 24 V AC coil - Schneider Electric - LC1K09004B72
TeSys K contactor - 4P (4 NO) - AC-1 <= 440 V 20 A - 24 V AC coil - Schneider Electric - LC1K09004B72

LC1K09004B72

TeSys K contactor - 4P (4 NO) - AC-1 <= 440 V 20 A - 24 V AC coil - Schneider Electric - LC1K09004B72

Control

List Price £43.67 +VAT

Our Price £32.75 +VAT

SAVE 26% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
TeSys K contactor, 4 poles (4NO), for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V 50/60Hz AC coil with transient suppressor module, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC),
Brand
Schneider Electric
Range
TeSys K contactors
Part No
LC1K09004B72
Weight (kg)
0.18 kg
Type
TeSys K contactors
Type of electrical connection of main circuit
Screw connection
Rated control supply voltage Us at AC 50HZ
24 V
Rated control supply voltage Us at AC 60HZ
24 V
Number of main contacts as normally open contact
4
Modular version
FALSE
Rated operation current Ie at AC-1, 400 V
20
Voltage type for actuating
AC

Datasheet for LC1K09004B72 - TeSys K contactor - 4P (4 NO) - AC-1 <= 440 V 20 A - 24 V AC coil - Schneider Electric - LC1K09004B72
