TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 110 V AC coil - Schneider Electric - LC1K090085F7

TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 110 V AC coil - Schneider Electric - LC1K090085F7

LC1K090085F7

TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 110 V AC coil - Schneider Electric - LC1K090085F7

Control

~~List Price £38.89 +VAT~~

Our Price £29.17 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. It provides a 110V 50/60Hz AC coil, without built-in auxiliary contact, connection by solder pins for printed circuit boards. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC),

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LC1K090085F7
Weight (kg): 0.21 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: PCB connection
Width: 45
Rated control supply voltage AC 50 Hz: 110 Volt
Rated control supply voltage AC 60 Hz: 110 Volt
Number of normally closed contacts as main contact: 2
Number of normally open contacts as main contact: 2
Modular version: FALSE
Operating voltage AC 50 Hz: 440 Volt
Depth: 57
Operating voltage AC 60 Hz: 440 Volt
Rated operation current Ie at AC-1, 400 V: 20
Voltage type for actuating: AC
Height: 58

Datasheet for LC1K090085F7 - TeSys K contactor - 4P (2 NO + 2 NC) - AC-1 <= 440 V 20 A - 110 V AC coil - Schneider Electric - LC1K090085F7

Download
