TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 24 V AC coil - Schneider Electric - LC1K09103B7

TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 24 V AC coil - Schneider Electric - LC1K09103B7

LC1K09103B7

TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 24 V AC coil - Schneider Electric - LC1K09103B7

Control

~~List Price £34.99 +VAT~~

Our Price £26.24 +VAT

SAVE 26% OFF List Price

Estimated delivery between 7-10 working days

TeSys K contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V), and for non-inductive load control applications up to 10A/690V AC-1. It provides a 24V 50/60Hz AC coil, 1NO built-in auxiliary contact, connection by spring terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC),

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LC1K09103B7
Weight (kg): 0.18 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Spring clamp connection
Rated control supply voltage Us at AC 50HZ: 24 V
Rated control supply voltage Us at AC 60HZ: 24 V
Rated operation power at AC-3, 400 V: 4
Number of main contacts as normally open contact: 3
Number of auxiliary contacts as normally open contact: 1
Modular version: TRUE
Rated operation power NEMA: 3.73
Rated operation current Ie at AC-1, 400 V: 10
Rated operation current Ie at AC-4, 400 V: 9
Rated operation current Ie at AC-3, 400 V: 9
Voltage type for actuating: AC
Rated operation power at AC-4, 400 V: 4
