TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 110 V DC coil - Schneider Electric - LP1K0910FD
TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 110 V DC coil - Schneider Electric - LP1K0910FD

LP1K0910FD

TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 110 V DC coil - Schneider Electric - LP1K0910FD

Control

List Price £41.02 +VAT

Our Price £30.77 +VAT

SAVE 25% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
"TeSys K contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V)," "and for non-inductive load control applications up to 20A/690V AC-1." It provides a 110V DC coil, 1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Brand
Schneider Electric
Range
TeSys K contactors
Part No
LP1K0910FD
Weight (kg)
0.22 kg
Type
TeSys K contactors
Type of electrical connection of main circuit
Screw connection
Rated operation power at AC-3, 400 V
4
Number of main contacts as normally open contact
3
Number of auxiliary contacts as normally open contact
1
Modular version
FALSE
Rated operation current Ie at AC-1, 400 V
20
Rated operation current Ie at AC-3, 400 V
9
Voltage type for actuating
DC
Rated operation current Ie at AC-4, 400 V
6
Rated control supply voltage Us at DC
110 V
Rated operation power at AC-4, 400 V
2.2

Datasheet for LP1K0910FD - TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NO aux. - 110 V DC coil - Schneider Electric - LP1K0910FD
