TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NC aux. - 24 V DC coil - Schneider Electric - LP1K0901BD

TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NC aux. - 24 V DC coil - Schneider Electric - LP1K0901BD

LP1K0901BD

TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NC aux. - 24 V DC coil - Schneider Electric - LP1K0901BD

Control

~~List Price £39.77 +VAT~~

Our Price £29.83 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

TeSys K contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V DC coil, 1NC built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LP1K0901BD
Weight (kg): 0.22 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Screw connection
Width: 45
Rated operation power at AC-3, 400 V: 4
Number of normally open contacts as main contact: 3
Number of auxiliary contacts as normally closed contact: 1
Modular version: FALSE
Depth: 57
Rated operation current Ie at AC-1, 400 V: 20
Rated operation current Ie at AC-3, 400 V: 9
Height: 58
Rated operation current Ie at AC-4, 400 V: 6
Rated control supply voltage DC: 24 Volt
Voltage type for actuating: DC
Rated operation power at AC-4, 400 V: 2.2

Datasheet for LP1K0901BD - TeSys K contactor - 3P - AC-3 <= 440 V 9 A - 1 NC aux. - 24 V DC coil - Schneider Electric - LP1K0901BD

Download
