TeSys K contactor - 3P - AC-3 <= 440 V 6 A - 1 NC aux. - 220 V DC coil - Schneider Electric - LP1K06013MD3

TeSys K contactor - 3P - AC-3 <= 440 V 6 A - 1 NC aux. - 220 V DC coil - Schneider Electric - LP1K06013MD3

LP1K06013MD3

TeSys K contactor - 3P - AC-3 <= 440 V 6 A - 1 NC aux. - 220 V DC coil - Schneider Electric - LP1K06013MD3

Control

~~List Price £56.41 +VAT~~

Our Price £42.31 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

"TeSys K contactor, 3 poles (3NO), for motor control applications up to 6A/690V AC-3 (4kW@400V)," "and for non-inductive load control applications up to 20A/690V AC-1." "It provides a 220V DC coil with integral suppression device, 1NC built-in auxiliary contact, connection by spring teminals." "For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications." "Very compact (45mm width), DIN-rail mounting or screw fixing." "Multi standards certified (IEC, UL, CSA, CCC, EAC)

Brand: Schneider Electric
Range: TeSys K contactors
Part No: LP1K06013MD3
Weight (kg): 0.22 kg
Type: TeSys K contactors
Type of electrical connection of main circuit: Spring clamp connection
Width: 45
Rated operation power at AC-3, 400 V: 2.2
Number of normally open contacts as main contact: 3
Number of auxiliary contacts as normally closed contact: 1
Modular version: FALSE
Operating voltage AC 50 Hz: 440 Volt
Depth: 57
Operating voltage AC 60 Hz: 440 Volt
Rated operation current Ie at AC-1, 400 V: 20
Voltage type for actuating: DC
Height: 58
Rated operation current Ie at AC-4, 400 V: 4
Rated operation current Ie at AC-3, 400 V: 6
Rated control supply voltage DC: 220 Volt
Rated operation power at AC-4, 400 V: 1.5

Datasheet for LP1K06013MD3 - TeSys K contactor - 3P - AC-3 <= 440 V 6 A - 1 NC aux. - 220 V DC coil - Schneider Electric - LP1K06013MD3

Download
