GV4P25B
TeSys GV4 - thermal magnetic circuit breaker - 25A 3P - with Everlink - Schneider Electric - GV4P25B
Automation
TeSys GV motor circuit breaker, 3 poles (3P), 25A/690V, for protection of 3-phase motors 5.5-11kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 25kA@400V, start-stop control by rotary handle, connection by Everlink BTR screw terminals. Thermal protection adjustable by dials with a setting current Ir in range 10-25A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
Our Price £337.79 +VAT
SAVE 26% OFF List Price
Specifications
- Brand
- Schneider Electric
- Type
- TeSys Deca - frame 4
- Range
- TeSys Deca - frame 4
- Part No
- GV4P25B
- Weight (kg)
- 1.84 kg
