GV4L50N6
TeSys GV4 - magnetic circuit breaker - 50A 3P - with compression lug - Schneider Electric - GV4L50N6
Automation
TeSys GV motor circuit breaker, 3 poles (3P), 50A/690V, for protection of 3-phase motors 11-22kW@400V. It provides magnetic protection, breaking capacity Icu 50kA@400V, start-stop control by rotary handle, connection for bars or cables with lugs. Magnetic protection adjustable by dial, setting range 6-14 In. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). To be used in association with a class 10 or 20 thermal overload relay to complete motor protection. Multi standards certified (IEC, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
Our Price £328.96 +VAT
SAVE 25% OFF List Price
Specifications
- Brand
- Schneider Electric
- Type
- TeSys Deca - frame 4
- Range
- TeSys Deca - frame 4
- Part No
- GV4L50N6
- Weight (kg)
- 1.65 kg
Datasheet for GV4L50N6 - TeSys GV4 - magnetic circuit breaker - 50A 3P - with compression lug - Schneider Electric - GV4L50N6
