Brand
-
Schneider Electric
-
Range
-
TeSys Deca contactors
-
Part No
-
LC1D80AE7
-
Weight (kg)
-
0.93 kg
-
Type
-
TeSys Deca contactors
-
Type of electrical connection of main circuit
-
Screw connection
-
Rated control supply voltage Us at AC 50HZ
-
48 V
-
Rated control supply voltage Us at AC 60HZ
-
48 V
-
Rated operation power at AC-3, 400 V
-
37
-
Number of main contacts as normally open contact
-
3
-
Number of auxiliary contacts as normally closed contact
-
1
-
Number of auxiliary contacts as normally open contact
-
1
-
Modular version
-
TRUE
-
Rated operation power NEMA
-
29.8
-
Rated operation current Ie at AC-1, 400 V
-
80
-
Rated operation current Ie at AC-4, 400 V
-
65
-
Voltage type for actuating
-
AC
-
Rated operation current Ie at AC-3, 400 V
-
66
-
Rated operation power at AC-4, 400 V
-
30
