TeSys D contactor - 4P(4 NO) - AC-1 - <= 440 V 200 A - 230 V AC 50/60 Hz coil - Schneider Electric - LC1D1150046P7
TeSys D contactor - 4P(4 NO) - AC-1 - <= 440 V 200 A - 230 V AC 50/60 Hz coil - Schneider Electric - LC1D1150046P7

LC1D1150046P7

TeSys D contactor - 4P(4 NO) - AC-1 - <= 440 V 200 A - 230 V AC 50/60 Hz coil - Schneider Electric - LC1D1150046P7

Control

List Price £740.66 +VAT

Our Price £555.50 +VAT

SAVE 25% OFF List Price
Estimated delivery between 7-10 working days
Get in touch
"TeSys Deca contactor, 4 poles(4NO) for category AC-1 applications up to 200A @440V." "It provides with 230V 50/60 Hz coil, with no auxiliary contacts, power and control connections by screw clamp terminals." It procures high reliability and durability with 8 Mcycles mechanical durability and 0.8 Mcycles electrical durability. It provides IP20 protection on front face conforming to IEC 60529. It can cover -40°C to 60°C operation temperature and without derating under 3000m altitude. "Designed for demanding applications with maximum operating rates up to 2400 cycles per hour under maximum 60°C." The dimension is 158mm x 155mm x 115mm (H x W x D), mounting on rail or plate. Multi standards certified(CCC,DNV,GL,CSA,GOST,BV,UL,LROS,RINA,UKCA).
Brand
Schneider Electric
Range
TeSys Deca contactors
Part No
LC1D1150046P7
Weight (kg)
2.37 kg
Type
TeSys Deca contactors
Type of electrical connection of main circuit
Other
Width
155
Rated control supply voltage AC 50 Hz
230 Volt
Rated control supply voltage AC 60 Hz
230 Volt
Number of normally open contacts as main contact
4
Modular version
FALSE
Operating voltage AC 50 Hz
440 Volt
Depth
115
Operating voltage AC 60 Hz
440 Volt
Rated operation current Ie at AC-1, 400 V
200
Voltage type for actuating
AC
Height
158

Datasheet for LC1D1150046P7 - TeSys D contactor - 4P(4 NO) - AC-1 - <= 440 V 200 A - 230 V AC 50/60 Hz coil - Schneider Electric - LC1D1150046P7

Download
