LC2D115004P7

TeSys D changeover contactor - 4P(4 NO) - AC-1 - <= 440 V 200 A - 230 V AC coil - Schneider Electric - LC2D115004P7

Control

~~List Price £1,490.77 +VAT~~

Our Price £1,118.08 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

Get in touch

TeSys Deca changeover contactor, 4 poles (4NO), for non-inductive load applications up to 200A/1000V AC-1. It provides 230V 50/60Hz AC coils, without build-in auxiliary contacts, power connections by 2 screw terminals, control by screw clamp terminals. For operating rates until 2400 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (334mm width), mounting on 2 DIN-rails or screw fixing. With pre-wired changeover power connections, mechanical and electrical interlock. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine),

Brand: Schneider Electric
Range: TeSys Deca contactors
Part No: LC2D115004P7
Weight (kg): 8.50 kg
Type: TeSys Deca contactors
Type of electrical connection of main circuit: Screw connection
Type of electrical connection for auxiliary- and control current circuit: Screw connection
Voltage type (operating voltage): AC
Rated operation current Ie at AC-1, 400 V: 200
Voltage type for actuating: AC
Height: 158
Rated operation current Ie at AC-3, 400 V: 115
Degree of protection (IP): IP20
Width: 334
Rated control supply voltage AC 50 Hz: 230 Volt
Rated control supply voltage AC 60 Hz: 230 Volt
Rail mounting possible: FALSE
Number of normally open contacts as main contact: 4
Number of auxiliary contacts as normally closed contact: 1
Number of auxiliary contacts as normally open contact: 1
Operating voltage AC 50 Hz: 440 Volt
Depth: 148
Operating voltage AC 60 Hz: 440 Volt
Function: Changeover contactor
Degree of protection (NEMA): Other
