LC3D180AB7

TeSys D - star delta starter - 3 x 3P (3 NO) - 18 A - 24 V AC coil - Schneider Electric - LC3D180AB7

Control

~~List Price £580.93 +VAT~~

Our Price £435.70 +VAT

SAVE 25% OFF List Price

Estimated delivery between 7-10 working days

TeSys Deca pre-assembled star-delta starter, for motor control applications up to 11kW@400V in delta connection. Plate mounted starter, open version, composed of 3 contactors LC1D with 24V 50/60Hz AC coils, 1NC built-in auxiliary contact on star, a time-delay contact block 1-30 sec. For operating rates until 30 starts/hour, maximum starting time 30 sec. Compact assembly (144mm width), screw fixing. Equipped with pre-wired star delta power connections, and mechanical interlock, the use of a thermal overload relay (to be ordered separately) is strongly recommended. Green Premium compliant (RoHS/REACh).

Brand: Schneider Electric
Range: TeSys Deca contactors
Part No: LC3D180AB7
Weight (kg): 1.59 kg
Type: TeSys Deca contactors
