Brand
-
Schneider Electric
-
Range
-
Harmony Analog
-
Part No
-
RMTK80BD
-
Weight (kg)
-
0.10 kg
-
Type
-
Harmony Analog
-
SIL according to IEC 61508
-
None
-
Inherently safe according to EN 60947-5-6 NAMUR
-
FALSE
-
Height
-
78
-
Rated supply voltage at DC
-
24 V
-
Depth
-
80
-
Number of output ranges 4 mA ... 20 mA
-
1
-
Type of power supply
-
Active
-
Number of channels
-
1
-
Galvanic separation between output to output
-
FALSE
-
Galvanic separation between input and output
-
FALSE
-
Galvanic separation between inputs
-
FALSE
-
Galvanic separation between supply voltage and all other current circuits
-
FALSE
-
Switching frequency
-
100
-
Switching voltage
-
10
-
Construction type of device
-
Other
-
Width
-
25
-
Mounting method
-
Snap mounting support rail
-
Operation temperature
-
0…60 °C
-
Type of electric connection
-
Spring clamp connection
-
Malfunction message output
-
FALSE
-
Degree of protection (IP)
-
IP20
-
Load
-
500 Ohm
-
Number of output ranges 0 mA ... 20 mA
-
1
-
Number of output ranges 0 V ... 10 V
-
1
