"PanelSeT SMX is a stainless steel 304L floor-standing enclosure designed for multi-purpose applications and resistance to corrosion" "It is designed for use in harsh environments and has an IK10 rating (IEC 62262) for high impact resistance and an IP55 rating (IEC 60529) for dust and water resistance" "This enclosure has a nominal height, width and depth of 2000mm, 1600mm and 600mm respectively" "The enclosure is made with a Scotch-Brite® brushed surface finish and consists of a body, a cable gland plate, two plain doors, four mounting plate brackets, and a locking system with handle on the door" "The doors can be opened up to 120°, allowing easy access to the equipment inside" "The enclosure has a three-point lock with a handle with 5mm double-bar insert" "The doors and the mounting plate brackets can be removed for maintenance purposes" "The net weight of the enclosure is 200kg and it complies with IEC 62208 standards"

Brand

Schneider Electric

Range

PanelSeT SMX

Part No

NSYSMX201660

Weight (kg)

212.00 kg

Type

Spacial SMX

Couplable

FALSE

With mounting plate

FALSE

Freestanding

FALSE

With glazed door

FALSE

Suitable for metrical mounting

FALSE

With cover

FALSE

RAL-number

7047

Transparent cover

FALSE

Height

2000

Degree of protection (IP)

IP55

Pitched roof

FALSE

Floor standing wall model

TRUE

Colour

Stainless steel

Width

1600

Intermediate mounting

FALSE

Surface finishing

Brushed/grinded

Number of doors

2

Material

Stainless steel

Corner model

FALSE

Number of locks

3

Suitable for outdoor set-up

FALSE

Material quality

Stainless steel 316 (V4A)

Suitable for wall mounting

FALSE

Depth

600

Suitable for wall built-in

FALSE

Pre-stamping

FALSE

Max. permissible load of the mounting plate according to IEC 62208

300

With door

TRUE

Mounting plate depth-adjustable

FALSE

Impact strength

IK10

With ventilation door

FALSE

EMC-version

FALSE

Degree of protection (NEMA)

12

With rear door

FALSE

Pole fastening

FALSE

Max. permissible load of the door(s) according to IEC 62208

50
