Brand
-
Schneider Electric
-
Range
-
Lighting & power sockets
-
Part No
-
NSYLAM3M
-
Weight (kg)
-
0.36 kg
-
Type
-
Lighting & power sockets
-
Material outer sheath
-
Polyvinyl chloride (PVC)
-
Screen over stranding
-
None
-
Nominal cross section conductor (AWG)
-
10
-
Permitted cable outer temperature during assembling/handling
-
-16…65 °C
-
Torsion resistant
-
TRUE
-
Outer diameter approx.
-
3
-
Permitted cable outer temperature after assembling without vibration
-
-10…60 °C
-
Screen over stranding element
-
None
-
Halogen free (acc. EN 60754-1/2)
-
TRUE
-
Nominal cross section conductor
-
1.5
-
Low temperature resistant (acc. EN 60811-504+505+506)
-
TRUE
-
Core insulation material
-
Polyvinyl chloride (PVC)
-
Nominal voltage U0
-
300
-
Specification material outer sheath
-
Other
-
Specification core insulation
-
Other
-
Min. permitted bending radius, stationary application/permanent installation
-
45
-
Min. permitted bending radius, moving application/free movement
-
90
-
Min. permitted bending radius, moving application with forced guidance
-
180
-
AWG size
-
16
-
Protective conductor
-
TRUE
-
Nominal voltage U
-
500
-
Colour outer sheath
-
Black
-
Stranding element
-
No
-
Cable width approx.
-
8
-
Cable height approx.
-
0.7
-
Number of cores
-
3
-
Core identification
-
Colour
-
Suspension element
-
None
-
Conductor category
-
Class 5 = flexible
-
Shape
-
Round
