"PanelSeT SM compact enclosure with mounting plate - 1600x1000x300 mm" - Schneider Electric - NSYSM1610302DP

NSYSM1610302DP

"PanelSeT SM compact enclosure with mounting plate - 1600x1000x300 mm" - Schneider Electric - NSYSM1610302DP

Enclosures

~~List Price £938.71 +VAT~~

Our Price £704.03 +VAT

SAVE 26% OFF List Price

Estimated delivery between 7-10 working days

PanelSeT SM is a multi-purpose steel compact monobloc floor-standing enclosure designed for use in harsh environments. It has a nominal height, width and depth of 1600mm, 1000mm and 300mm respectively. The enclosure is made in grey color (RAL7035) with an epoxy-polyester powder surface finish and the handle is made in black color (RAL9005) It consists of one body, two plain doors, one cable gland plate with one entry, one plain mounting plate and four mounting plate brackets. The doors can be opened up to 120°, allowing easy access to the equipment inside. The enclosure has a four-point lock with a handle with 5mm double-bar insert. The doors, the mounting plate and the mounting plate brackets can be removed for maintenance purposes. It is certified by BV and UL and marine certified by DNV. This enclosure has IP55 ingress protection rating against dust and water and IK10 impact protectoin rating.

Brand: Schneider Electric
Range: PanelSeT SM
Part No: NSYSM1610302DP
Weight (kg): 115.00 kg
Type: Spacial SM
Couplable: FALSE
With mounting plate: TRUE
Freestanding: FALSE
With glazed door: FALSE
Suitable for metrical mounting: TRUE
With cover: FALSE
RAL-number: 7035
Transparent cover: FALSE
Height: 1600
Degree of protection (IP): IP55
Pitched roof: FALSE
Floor standing wall model: TRUE
Colour: Grey
Width: 1000
Intermediate mounting: FALSE
Surface finishing: Powder coating
Number of doors: 2
Material: Steel
Corner model: FALSE
Suitable for outdoor set-up: FALSE
Number of locks: 1
Material quality: Other
Suitable for wall mounting: FALSE
Suitable for wall built-in: FALSE
Depth: 300
Pre-stamping: FALSE
Max. permissible load of the mounting plate according to IEC 62208: 3973
With door: TRUE
Mounting plate depth-adjustable: FALSE
Impact strength: IK10
With ventilation door: FALSE
EMC-version: FALSE
Degree of protection (NEMA): 13
With rear door: FALSE
Pole fastening: FALSE
Max. permissible load of the enclosure according to IEC 62208: 4900
Max. permissible load of the door(s) according to IEC 62208: 588

Datasheet for NSYSM1610302DP - "PanelSeT SM compact enclosure with mounting plate - 1600x1000x300 mm" - Schneider Electric - NSYSM1610302DP

Download
