LC1G500EHEA
LC1G500EHEA
High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 500A, advanced version, 48…130V wide band AC/DC coil - Schneider Electric - LC1G500EHEA
Control
List Price £2,470.30
+VAT
Our Price £1,852.73
+VAT
SAVE 25% OFF List Price
Add to basket
Estimated delivery between 7-10 working days
Product description
Specifications
Downloads
TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 500A 315kW@440V. equipped with 48-130V AC/DC wide band low consumption electronic coil, PLC output control and embedded with highly reliable 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 500 cycles per hour and environments up to 60°C. It’s built with high reliability delivering mechanical durability up to 8 million cycles. Contact Wear Diagnosis (CWD) is a standard function, It continuously monitors and provide feedback through healthy and alarm conditions by an LED indicator. Remote signaling of wear diagnosis is enabled by an optional Remote Wear Diagnosis (RWD) module. It is possible to replace switching module (main contacts), control module enhancing contactor life and maintenance possible without removing main power cables/busbars, thanks to cable-memory connection blocks. Front accessible main power connections are with bolted connection and control connections by push-in terminals and easy and quick assembly. It provides IP2x protection from front face with optional terminal shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, with no derating up to 3000m altitude. Contactor can be installed in three quadrants of vertical plane, and OLR could be directly mounted below contactor. The dimensions are 290mm x 140mm x 226mm (H x W x D), compact size enables panel space savings. Multi standards certified (CB, CCC, cULcs, CE, UKCA marking). Multi standards certified (CB, CCC, cULcs, CE, UKCA marking).
Brand
Schneider Electric
Range
TeSys Giga contactors
Part No
LC1G500EHEA
Weight (kg)
9.17 kg
Datasheet for LC1G500EHEA - High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 500A, advanced version, 48…130V wide band AC/DC coil - Schneider Electric - LC1G500EHEA
Download
