frequency control relay RM35-HZ - range 40..70 Hz - Schneider Electric - RM35HZ21FM

frequency control relay RM35-HZ - range 40..70 Hz - Schneider Electric - RM35HZ21FM

RM35HZ21FM

frequency control relay RM35-HZ - range 40..70 Hz - Schneider Electric - RM35HZ21FM

Control

~~List Price £179.70 +VAT~~

Our Price £134.78 +VAT

SAVE 25% OFF List Price

Fast Track Delivery Product

This Harmony RM35-HZ control relay allows monitoring of frequency control. This modular control relay is ideal for monitoring of frequency variations in electrical power sources such as wind turbine and micro-power stations. It has one of market medium form-factors with 35mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 3-pole DIN device. It also offers a selectable memory function, integral LED for indicating control status, sealable cover, with simple and precise settings with screw trimmers. It provides an automatic detection of abnormal electrical values before they incur serious damage to machinery thus reducing your maintenance and downtime costs. Multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC. 0 0 0 0 0 0 0 0 0 0 0 0 0

Brand: Schneider Electric
Range: Harmony Control Relays
Part No: RM35HZ21FM
Weight (kg): 0.13 kg
Type: Harmony Control Relays
Width: 35
Rated control supply voltage Us at AC 50HZ: 120…277 V
Response value for frequency: 40…70 Hz
Rated control supply voltage Us at AC 60HZ: 120…277 V
Type of electric connection: Screw connection
Rated voltage: 120…277 V
Depth: 72
Number of contacts as change-over contact: 2
Height: 90
Voltage type for actuating: AC
With detachable clamps: FALSE
Max. permitted delay-on energization time: 10
Min. adjustable delay-on energization time: 0.1
Max. permitted off-delay time: 10
Min. adjustable off-delay time: 0.1

Datasheet for RM35HZ21FM - frequency control relay RM35-HZ - range 40..70 Hz - Schneider Electric - RM35HZ21FM
