"This PLA version of the Thalassa is a multi-purpose, floor-standing enclosure that is suitable for various applications" "It has nominal dimensions of 750mm in height, 1000mm in width, and 320mm in depth, and is made of polyester reinforced with fiberglass, offering durability and resistance to harsh environments, both indoor and outdoor" "This enclosure is available in grey (RAL 7035) color and consists of two side parts, two plain front doors, and two rear panels" "The doors can be opened from both the right and left sides, up to 120°, and feature a two-point lock with a 5mm double-bar insert" "The doors and rear panels are also removable for maintenance purposes" "The enclosure offers robust protection against various hazards, including fire, impact, dust, and water" "It can withstand fire up to 960°C in accordance with the IEC 62208 standard" "The enclosure also has an IK10 rating (IEC 62262), indicating high resistance to impacts" "It is rated IP65 (IEC 60529), offering complete protection against dust and water" "Additionally, the enclosure has class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions" "It is UL/cUL listed, DNV Marine certified, and can be stored in ambient air temperatures ranging from -35°C to 90°C without affecting its performance"

Brand

Schneider Electric

Range

PanelSeT PLA

Part No

NSYPLA7103G

Weight (kg)

28.38 kg

Type

Thalassa PLA

With mounting plate

FALSE

With glazed door

FALSE

Wall fastening possible

FALSE

Suitable for metrical mounting

FALSE

RAL-number

7035

Tackable

FALSE

Height

750

Degree of protection (IP)

IP65

Pitched roof

FALSE

Colour

Grey

Width

1000

Surface finishing

Untreated

Number of doors

2

Material

Plastic

Suitable for outdoor set-up

TRUE

Number of locks

1

Material quality

Polyester

Wall build in

FALSE

Depth

320

Mounting plate depth-adjustable

FALSE

Impact strength

IK10

With ventilation door

FALSE

EMC-version

FALSE

Degree of protection (NEMA)

13

With backside door

FALSE

Pole fastening

FALSE

Floor installation possible

TRUE
