"This PLA version of the Thalassa PLA is a multi-purpose, floor-standing enclosure that is suitable for various applications" "It measures 500mm in height, 750mm in width, and 320mm in depth" "Made of polyester reinforced with fiberglass, the enclosure is designed to provide durability and resistance to harsh environments, including outdoor and industrial settings" "It is available in grey (RAL 7035)" "The enclosure consists of two side parts, one plain front door, one rear panel, and a sealed top and bottom part" "The door can open up to 120° from either the right or left side, and features a two-point lock with a 5mm double-bar insert" "The door and rear panel are removable for maintenance purposes" "The enclosure offers robust protection against various hazards, including fire, impacts, dust, and water" "It can withstand fire up to 960°C in accordance with the IEC 62208 standard" "It has an IK10 rating (IEC 62262), indicating high resistance to impacts" "It is also rated IP65 (IEC 60529), offering complete protection against dust and water" "Additionally, the enclosure has class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions" "It is DNV Marine and Veritas certified, and UL/cUL listed" "It can be stored in ambient air temperatures ranging from -35°C to 90°C without affecting its performance"

Brand

Schneider Electric

Range

PanelSeT PLA

Part No

NSYPLA573G

Weight (kg)

18.22 kg

Type

Thalassa PLA

With mounting plate

FALSE

With glazed door

FALSE

Wall fastening possible

FALSE

Suitable for metrical mounting

FALSE

RAL-number

7035

Tackable

FALSE

Height

500

Degree of protection (IP)

IP65

Pitched roof

FALSE

Colour

Grey

Width

750

Surface finishing

Untreated

Material

Plastic

Number of doors

1

Suitable for outdoor set-up

TRUE

Number of locks

1

Material quality

Polyester

Depth

320

Wall build in

FALSE

Mounting plate depth-adjustable

FALSE

Impact strength

IK10

With ventilation door

FALSE

EMC-version

FALSE

Degree of protection (NEMA)

13

Pole fastening

FALSE

With backside door

FALSE

Floor installation possible

TRUE
