Floor standing enclosure polyester vers.PLA completely sealed 500x1000x420 IP65 - Schneider Electric - NSYPLA5104G
Floor standing enclosure polyester vers.PLA completely sealed 500x1000x420 IP65 - Schneider Electric - NSYPLA5104G

NSYPLA5104G

Floor standing enclosure polyester vers.PLA completely sealed 500x1000x420 IP65 - Schneider Electric - NSYPLA5104G

Enclosures

List Price £727.83 +VAT

Our Price £545.87 +VAT

SAVE 26% OFF List Price
Estimated delivery between 7-10 working days
"This PLA is a versatile, floor-standing enclosure that is suitable for various applications" "The enclosure measures 500mm in height, 1000mm in width, and 420mm in depth, and is made of polyester reinforced with fiberglass" "This material provides the enclosure with durability and resistance to harsh environments, both indoor and outdoor" "The enclosure is available in grey (RAL 7035) color and comprises two side parts, two plain front doors, and two rear panels" "The doors can be opened from both the right and left sides, up to 120°, and feature a two-point lock with a handle that has a 5mm double-bar insert" "The doors and rear panels are also removable for maintenance purposes" "The enclosure offers robust protection against various hazards, including fire, impact, dust, and water" "It can withstand fire up to 960°C in accordance with the IEC 62208 standard" "The enclosure also has an IK10 rating (IEC 62262), indicating high resistance to impacts" "It is rated IP65 (IEC 60529), offering high protection against dust and water" "Additionally, the enclosure has class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions" "It is UL/cUL listed and DNV Marine certified, and can be stored in ambient air temperatures ranging from -35°C to 90°C without affecting its performance"
Brand
Schneider Electric
Range
PanelSeT PLA
Part No
NSYPLA5104G
Weight (kg)
33.14 kg
Type
Thalassa PLA

Datasheet for NSYPLA5104G - Floor standing enclosure polyester vers.PLA completely sealed 500x1000x420 IP65 - Schneider Electric - NSYPLA5104G
