"This PLA is a multi-purpose, floor-standing unit that is suitable for various applications" "It has a nominal height of 1000mm, a width of 1250mm, and a depth of 420mm" "The enclosure is made of polyester reinforced with fiberglass, providing durability and resistance to harsh environments" "It is available in grey (RAL 7035) color and consists of two side parts, two transparent front doors, and two rear panels" "The doors can open up to 120° from either the right or left side, and feature a four-point lock with a 5mm double-bar insert" "The doors and rear panels are removable for easy maintenance" "The enclosure offers robust protection against various hazards, including fire, impacts, dust, and water" "It can withstand fire up to 960°C in accordance with the IEC 62208 standard, and has an IK08 rating (IEC 62262) for resistance to impacts" "It is rated IP65 (IEC 60529), offering complete protection against dust and water" "Additionally, the enclosure has Class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions" "It is DNV Marine, UL/cUL listed, and Veritas certified, and can be stored in ambient air temperatures ranging from -35°C to 90°C without affecting its performance"

Brand

Schneider Electric

Range

PanelSeT PLA

Part No

NSYPLA10124TG

Weight (kg)

54.00 kg

Type

Thalassa PLA

Couplable

FALSE

With mounting plate

FALSE

Freestanding

FALSE

With glazed door

TRUE

Suitable for metrical mounting

FALSE

With cover

FALSE

RAL-number

7035

Transparent cover

FALSE

Height

1000

Degree of protection (IP)

IP65

Pitched roof

FALSE

Floor standing wall model

FALSE

Colour

Grey

Width

1250

Intermediate mounting

FALSE

Surface finishing

Untreated

Number of doors

2

Material

Plastic

Number of locks

1

Corner model

FALSE

Suitable for outdoor set-up

TRUE

Suitable for wall mounting

TRUE

Material quality

Polyester (PET)

Suitable for wall built-in

FALSE

Depth

420

Pre-stamping

FALSE

Max. permissible load of the mounting plate according to IEC 62208

1304

With door

TRUE

Mounting plate depth-adjustable

FALSE

Impact strength

IK08

With ventilation door

FALSE

EMC-version

FALSE

Degree of protection (NEMA)

4

With rear door

FALSE

Pole fastening

FALSE

Max. permissible load of the enclosure according to IEC 62208

1814

Max. permissible load of the door(s) according to IEC 62208

147
