"This product is part of the Harmony K range, an offer of Ø 16-22mm rotary cam switches." "This cam switch comes with standard handle and 0 - 1 black marking metallic legend." "The switch features 90° switching angle and 0° - 90° right switching position." "It is a 2-pole stepping switch with a rated voltage of 690V and a conventional free air thermal current of 20A." "It is furnished with screw clamp terminals for electrical connection." "It offers electrical durability of about 200 cycles and mechanical durability of about 1 million cycles. It is an IP40 rated product." "The cam switch dimensions are 45mm (width) x 77mm (depth) x 45mm (height). It weighs 0.13kg." "It is ideal for oil and gas, food and beverage, packaging, kneading trough and vegetable cutting machine applications." "This product is certified by CULus. It meets CENELEC EN 50013, EN/IEC 60947-3 and EN/IEC 60947-5-1 standards." "It supports front mounting method with multi fixing." "Modular rotary cam switches from 10A to 150A with plastic or metal heads meet most industrial applications."

Brand

Schneider Electric

Range

Harmony K

Part No

K2B1002HLH

Weight (kg)

0.14 kg

Type

Harmony K

Type of electrical connection of main circuit

Screw connection

With 0 (off) position

TRUE

With retraction in 0-position

FALSE

Type of control element

Long turning handle

Model

On/Off switch

Material housing

Other

Degree of protection (IP), front side

IP40

Rated permanent current Iu

20

Complete device in housing

TRUE

Number of poles

2

Suitable for front mounting 4-hole

TRUE

Degree of protection (NEMA), front side

Other

Suitable for distribution board installation

FALSE

Rated operation current Ie at AC-3, 400 V

8

Suitable for intermediate mounting

TRUE

Suitable for ground mounting

FALSE
