cam switch - 2-pole - 45° - 20 A - screw mounting - Schneider Electric - K2B002ALH

cam switch - 2-pole - 45° - 20 A - screw mounting - Schneider Electric - K2B002ALH

K2B002ALH

cam switch - 2-pole - 45° - 20 A - screw mounting - Schneider Electric - K2B002ALH

Control

~~List Price £26.76 +VAT~~

Our Price £20.07 +VAT

SAVE 26% OFF List Price

Estimated delivery between 7-10 working days

This Harmony K2 cam switch/selector switch has 2 poles (2P). It also has a rating of 20A, a screw clamp mounting mode and a metallic color with black marking. It has "0 - 1" marking to indicate the position of the switch. This metal head cam switch/selector switch is designed to meet most industrial and process control application thanks to a compact size, an easy integration with 16mm and 22mm diameter units and has several selection functions. It has a 45 degree between its switching positions.

Brand: Schneider Electric
Range: Harmony K
Part No: K2B002ALH
Weight (kg): 0.13 kg
Type: Harmony K
With 0 (off) position: TRUE
With retraction in 0-position: FALSE
Type of electrical connection of main circuit: Screw connection
Model: On/Off switch
Type of control element: Long turning handle
Material housing: Other
Degree of protection (IP), front side: IP40
Rated permanent current Iu: 20
Complete device in housing: TRUE
Number of poles: 2
Suitable for front mounting 4-hole: TRUE
Degree of protection (NEMA), front side: Other
Suitable for distribution board installation: FALSE
Rated operation current Ie at AC-3, 400 V: 8
Suitable for intermediate mounting: TRUE
Suitable for ground mounting: FALSE

Datasheet for K2B002ALH - cam switch - 2-pole - 45° - 20 A - screw mounting - Schneider Electric - K2B002ALH

Download
