"This ETHWAY module is part of the Modicon X80 range, an offer of common IO modules, communication modules, power supplies, and backplanes for Modicon M340 and Modicon M580 automation platforms." "Its power consumption is 1,1A on the 3,3V supply of the bus (peak at 1,7A)." "It supports 3 types of functions (UNITE Server, UNITE Client and Common Words)." "Thanks to this module, the Modicon M580 processor can access a subnetwork using a station from its network as a bridge." "One ETHWAY module should be installed for each M580 controller that is integrated into the ETHWAY network." "This ETHWAY module has dimensions of 32x100x86mm." "It allows the Modicon M340 and Modicon M580 processors to communicate with legacy TSX7 and Premium PLCs via the Ethway protocol during a migration campaign." "This module is designed by Prosyst, a Schneider Electric TPP partner." "This module helps connect the Modicon M580 processor to Premium or TSX Series 7 legacy processors." "This Modicon X80 module is to be installed on the X bus rack and fixed with 2 screws." "The Modicon range is tailored for easy migration of legacy products." "Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs."

Brand

Schneider Electric

Range

Modicon X80 I/Os

Part No

PMXETW0100

Weight (kg)

0.00 kg

Type

Modicon X80 I/Os

Supporting protocol for SERCOS

FALSE

Number of HW-interfaces USB

1

With optical interface

FALSE

Transmission rate

10000

With potential separation

FALSE

Radio standard GPRS

FALSE

Height

97

Supporting protocol for INTERBUS-Safety

FALSE

Width

32

Redundancy

FALSE

Supporting protocol for AS-Interface Safety at Work

FALSE

Radio standard GSM

FALSE

Radio standard UMTS

FALSE

Depth

104

Supporting protocol for DeviceNet Safety

FALSE

Supporting protocol for EtherNet/IP

TRUE

Supporting protocol for Foundation Fieldbus

FALSE

Supporting protocol for SafetyBUS p

FALSE

Supporting protocol for PROFINET CBA

FALSE

Supporting protocol for PROFINET IO

FALSE

Supporting protocol for PROFIsafe

FALSE

Supporting protocol for ASI

FALSE

Radio standard Bluetooth

FALSE

Radio standard WLAN 802.11

FALSE

Supporting protocol for PROFIBUS

FALSE

Type of data transmission

Module rack extension

Supporting protocol for TCP/IP

TRUE

Supporting protocol for KNX

FALSE

Supporting protocol for CAN

FALSE

IO link master

FALSE

Supporting protocol for INTERBUS

FALSE

Supporting protocol for DeviceNet

FALSE

Supporting protocol for MODBUS

FALSE

Supporting protocol for Data-Highway

FALSE

Supporting protocol for LON

FALSE

Supporting protocol for other bus systems

FALSE

Supporting protocol for SUCONET

FALSE

Number of HW-interfaces industrial Ethernet

1
